1. Parameters:
Rated energy(kWh): 5.12KWh
Configuration: 2P16S
Nominal Voltage(V): 51.2V
Working Voltage(V): 42V~58.4V
Nominal Capacity(Ah): 100Ah
Rated charge/discharge Current(A): 50A@25±2℃
Maximum charging current: 100A@25±2℃
Maximum discharge current: 100A @25±2℃
Working Temperature: 0～40℃(Charge)
Configuration: 2P16S
Nominal Voltage(V): 51.2V
Working Voltage(V): 42V~58.4V
Nominal Capacity(Ah): 100Ah
Rated charge/discharge Current(A): 50A@25±2℃
Maximum charging current: 100A@25±2℃
Maximum discharge current: 100A @25±2℃
Working Temperature: 0～40℃(Charge)
-20～40℃(Discharge)
Humidity(%): 5~95%
Altitude Limited(m): 0-3000m
Dimension(mm): 544.7×432.5×166mm
Storage temperature and humidity: -10℃~35℃（Within one month of storage）
25±2℃（Within three months of storage）65%±20%RH
Weight: 47kg±3kg
Cycle life: 4800 cycles @25℃ 50A charge and discharge current 70% standard capacity 90% DOD
IP grade: IP20
Communication mode: CAN&RS485
Humidity(%): 5~95%
Altitude Limited(m): 0-3000m
Dimension(mm): 544.7×432.5×166mm
Storage temperature and humidity: -10℃~35℃（Within one month of storage）
25±2℃（Within three months of storage）65%±20%RH
Weight: 47kg±3kg
Cycle life: 4800 cycles @25℃ 50A charge and discharge current 70% standard capacity 90% DOD
IP grade: IP20
Communication mode: CAN&RS485
2.Features:
1. Prismatic LiFePO4 Grade A Cell
2. High safety
3. Sufficient capacity
4. Get better performance
2. High safety
3. Sufficient capacity
4. Get better performance
3. Details:
