1. Parameters:
Configuration:4P16S
Nominal Voltage(V):51.2V
Working Voltage(V):41.6V~58.4V
Nominal Capacity(Ah):200Ah
Rated energy(kWh):10.24KWh
Rated charge/discharge Current(A):50A @25±2℃
Maximum charging current:100A@25±2℃
Maximum discharge current:100A @25±2℃
Working Temperature: 0～40℃(Charge)-10～40℃(Discharge)
Storage temperature and humidity:-10℃~35℃（Within one month of storage）
Nominal Voltage(V):51.2V
Working Voltage(V):41.6V~58.4V
Nominal Capacity(Ah):200Ah
Rated energy(kWh):10.24KWh
Rated charge/discharge Current(A):50A @25±2℃
Maximum charging current:100A@25±2℃
Maximum discharge current:100A @25±2℃
Working Temperature: 0～40℃(Charge)-10～40℃(Discharge)
Storage temperature and humidity:-10℃~35℃（Within one month of storage）
25±2℃（Within three months of storage）65%±20%RH
Dimension(mm):920×550×205mm
Weight:95Kg±3kg
Cycle life:4800 cycles @25℃ 50Acharge and discharge current 90% DOD
IP grade:IP 65
Dimension(mm):920×550×205mm
Weight:95Kg±3kg
Cycle life:4800 cycles @25℃ 50Acharge and discharge current 90% DOD
IP grade:IP 65
Communication mode:CAN&RS485
Altitude Limited(m):0-3000m
Humidity(%):5~80%
Humidity(%):5~80%
2.Features:
1. High cycle life, safe and stable
2. Secondary escape design protection
3. Parallel one-key switch
4. UL94-VO sun burning module
5. Safe, stable and superior performance
6. Suitable for parallel, off-grid, etc.
2. Secondary escape design protection
3. Parallel one-key switch
4. UL94-VO sun burning module
5. Safe, stable and superior performance
6. Suitable for parallel, off-grid, etc.
7. Compatible with many mainstream inverters
8. Supports parallel connection of up to 16 batteries
9. Green, environmentally friendly and pollution-free
10. Variety of styles to choose from
